Figure [SeD-02] Service ABEs Level 1 & 2

The diagram below lists the Customer Domain's ABEs Level 1 and Level 2.
Customer Facing Service Spec ABE

• The Customer Facing Service Spec ABE defines the common characteristics for a set of CustomerFacingServices. This scales by enabling multiple CustomerFacingServiceSpecs to be defined to model the common characteristics of different groups of CustomerFacingServices.

Resource Facing Service Spec ABE

• The Resource Facing Service Spec ABE defines the common characteristics for a set of ResourceFacingServices. This scales by enabling multiple ResourceFacingServiceSpecs to be defined to model the common characteristics of different groups of ResourceFacingServices.

Service Catalog ABE

• A collection of entities that represent the specification of ServiceCatalogs and catalogs described by them that contain ServiceSpecifications.

Customer Facing Service ABE

• The Customer Facing Service ABE defines the characteristics of a particular CustomerFacingService that represents a realization of a Product within an organization's infrastructure.

Resource Facing Service ABE

• ResourceFacingService is an abstraction that defines the characteristics of a particular Service which support the network/infrastructure facing part of the service. For example, a VPN is an example of a CustomerFacingService, while the sub-services that perform different types of routing between network devices making up the VPN are examples of ResourceFacingServices.  ResourceFacingServices are "internal" Services that are required to support a CustomerFacingService.

Service Level Spec ABE

• This ABE includes a third type of Service Specification entity: that of a ServiceLevelSpecification. This type of specification templatizes Services that are bound to a Service Level Agreement.

Service Performance Specification ABE

• The Service Performance Specification ABE defines measure of the manner in which a Service is functioning.
